5536274-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Board to Board & Mezzanine Connectors 140 PLUG VT 145 30AU AP
PDF
/
Inventory: 6507
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold, Tin
Mount Through Hole
Housing Material Thermoplastic
PCB Mounting Orientation Vertical
Technical
Termination Press-Fit
ECCN Code EAR99
Connector Type Pin, Plug
Number of Positions 140
Max Operating Temperature 257°C
Min Operating Temperature -85°C
Color Natural
Number of Rows 2
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
Pitch 1.2446mm
Total Number of Contacts 140
Orientation Straight
Number of Conductors ONE
Reliability COMMERCIAL
Body Length or Diameter 3.714 inch
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 5
PCB Contact Pattern STAGGERED
Contact Gender MALE
Body Depth 0.34 inch
Contact Style SQ PIN-SKT
Insulation Resistance 5000000000Ohm
ELV Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 500VAC V
Durability 50 Cycles
Contact Pattern RECTANGULAR
Contact Rating (Current) 10.5A
Preloaded Yes
Dimensions
Height 8.624621mm
Plating Thickness 30μin
Length - Termination 0.145 inch
Length - Tail 3.683mm
Stack Height 10.92mm
Compliance
RoHS Status RoHS Compliant
