530785-3
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
POLARIZED PANEL MOUNTABLE Rectangular Connector Header
PDF
/
Inventory: 8194
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Mounting Type BOARD
Number of Pins 90
Mounting Option 1 HOLE .087-.098
Mounting Style RIGHT ANGLE
Board Mounting Option HOLE .086-.098
Mounting Option 2 NON-THREADED
Technical
JESD-609 Code e3
Pbfree Code no
ECCN Code EAR99
Connector Type BOARD CONNECTOR
Number of Rows 2
Additional Feature POLARIZED, PANEL MOUNTABLE
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating GOLD (50) OVER NICKEL
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 40
Terminal Pitch 1.91mm
Military Standard MIL-DTL-55302
Number of Conductors ONE
Body Length or Diameter 2.45 inch
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Mating Information NO
Body Breadth 0.31 inch
Contact Gender MALE
Body Depth 0.5 inch
Contact Style SQ PIN-SKT
Mating Contact Pitch 0.075 inch
Body/Shell Style RECEPTACLE
Termination Type SURFACE MOUNT
Polarization Key POLARIZED KEY
Contact Finish Termination Tin (Sn)
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.125 inch
Dimensions
Plating Thickness 50μin
Compliance
RoHS Status Non-RoHS Compliant
