5176837-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HDR BRKWAY 14POS R/A GOLD
PDF
/
Inventory: 8689
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
PCB Thickness 1.6002mm
Length - Tail 2.6mm
Contact Finish Thickness - Mating 203.2 nm
Plating Thickness 30μin
Height 5.4864mm
Technical
Contact Rating (Current) 1A
Mating Post Length 4mm
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 650VAC V
ELV Compliant
Insulation Resistance 1GOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 1A
Operating Supply Voltage 200V
Lead Length 2.6mm
UL Flammability Code 94V-0
Contact Gender MALE
Body Breadth 0.165 inch
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 3.9878mm
Number of Contacts 14
Number Of PCB Rows 2
Shrouding No
Row Spacing - Mating 2 mm
Body Length or Diameter 0.551 inch
Approval Agency CSA
Reliability COMMERCIAL
Number of Conductors ONE
Orientation Right Angle, Horizontal
Pitch 2.0066mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 2
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Through Hole
Pbfree Code yes
JESD-609 Code e3
Packaging Bulk
Physical
PCB Mount Retention Without
PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Contact Shape Square
Mount Through Hole
Contact Plating Gold
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
