5149011-3
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Backplane M 80 POS 1.27mm Solder ST Thru-Hole
PDF
/
Buying Options
Total Price: USD $28.89
Unit Price: USD $28.890848
≥1 USD $28.890848
≥10 USD $27.255521
≥100 USD $25.712754
≥500 USD $24.257313
≥1000 USD $22.884254
Inventory: 5908
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Stack Height 18.7452mm
Length - Tail 3.18mm
Plating Thickness 30μin
Length 56.24mm
Height 16.46mm
Technical
Preloaded Yes
Mating Post Length 4.826mm
Contact Pattern RECTANGULAR
Durability 50 Cycles
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Insulation Resistance 5000000000Ohm
Contact Style SQ PIN-SKT
Contact Gender MALE
PCB Contact Pattern STAGGERED
Number of Contacts 80
Number Of PCB Rows 5
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Number of Conductors ONE
Depth 7.24mm
Orientation Straight
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Color Natural
Min Operating Temperature -85°C
Max Operating Temperature 257°C
Connector Type Plug, Tab
Termination Solder
Pbfree Code yes
Physical
PCB Mounting Orientation Vertical
Housing Material Thermoplastic
Contact Shape Square
Mount Through Hole
Contact Plating Gold, Tin
Contact Material Bronze
