5149009-8
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Board to Board & Mezzanine Connectors MS,738PLUG,180, ASSY,095
PDF
/
Inventory: 2845
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Stack Height 18.7452mm
Length - Tail 2.41mm
Length - Termination 0.095 inch
Plating Thickness 30μin
Height 16.46mm
Technical
Preloaded Yes
Mating Post Length 4.826mm
Contact Pattern RECTANGULAR
Durability 50 Cycles
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Insulation Resistance 5000000000Ohm
Contact Style SQ PIN-SKT
Body Depth 0.648 inch
Contact Gender MALE
PCB Contact Pattern STAGGERED
Number Of PCB Rows 5
Row Spacing - Mating 2.54 mm
Body Length or Diameter 4.714 inch
Reliability COMMERCIAL
Number of Conductors ONE
Orientation Straight
Total Number of Contacts 180
Pitch 1.27mm
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Color Natural
Min Operating Temperature -85°C
Max Operating Temperature 257°C
Number of Positions 180
Connector Type Plug, Tab
Termination Solder
Physical
PCB Mounting Orientation Vertical
Housing Material Thermoplastic
Contact Shape Square
Mount Through Hole
Contact Plating Gold, Tin
Contact Material Bronze
