5-147024-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Inventory: 8422
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
High Speed Serial Data Connector No
High Temperature Housing Yes
Mating Post Length 8.13mm
ELV Compliant
Lead Length 6.35mm
Housing Color Black
Contact Length - Mating 5.08mm
Number of Contacts 20
Row Spacing - Mating 2.54 mm
Orientation Vertical
Pitch 2.54mm
Number of Rows 2
Color Black
Number of Positions 20
Connector Type Male Pin
Termination Press-Fit
Packaging Bulk
Physical
Housing Material Thermoplastic
Contact Shape Square
Mount Through Hole
Contact Plating Tin
Contact Material Copper, Nickel, Tin
