RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Male Pin Rectangular Connector
PDF
/
Inventory: 5617
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Stack Height 19.5mm

Technical

ELV Compliant
Lead Length 11.4mm
Housing Color Black
Number of Contacts 26
Row Spacing - Mating 2.54 mm
Approval Agency CSA, UL
Current Rating 3A
Pitch 2.54mm
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature -125°C
Number of Positions 26
Connector Type Header, Pin, Plug
Termination Solder
Packaging Bulk

Physical

Housing Material PBT
Contact Shape Square
Mount Through Hole
Contact Plating Gold
