350211-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
MATE-N-LOK POLARIZATION AVAILABLE Rectangular Connector Header
PDF
/
Inventory: 9554
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
PCB Thickness 1.57mm
Plating Thickness 2.54μm
Width 9.53mm
Length 25.4mm
Height 8.26mm
Technical
VDE Tested No
Contact Rating (Current) 12A
Circuit Application Power
Max Voltage Rating (AC) 250V
Empty Shell NO
Contact Gender Male
Contact Length - Mating 4.572mm
Number of Contacts 4
Approval Agency CSA
Depth 9.65mm
Pitch 5.08mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating GOLD (30) OVER NICKEL
Additional Feature MATE-N-LOK, POLARIZATION AVAILABLE
Number of Rows 1
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 221°C
Connector Type Pin
Termination Solder
Pbfree Code no
JESD-609 Code e0
Packaging Bulk
Physical
PCB Mounting Orientation Vertical
Housing Material Nylon
Shell Material POLYAMIDE
Mount Through Hole
Contact Plating Gold, Tin
Contact Material Bronze
