Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Headers & Wire Housings IDC LOW PRO HDR 64P VERT BLUE
PDF
/
Inventory: 9431
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Length 88.9mm

Technical

Max Voltage Rating (AC) 250V
ELV Compliant
Lead Length 4.19mm
UL Flammability Code 94V-0
Contact Gender Male
Contact Length - Mating 6.096mm
Number of Contacts 64
Row Spacing - Mating 2.54 mm
Depth 9.22mm
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 2
Color Blue
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Connector Type Header
Termination Solder
Pbfree Code yes
JESD-609 Code e3
Packaging Bulk

Physical

PCB Mounting Orientation Vertical
Housing Material PBT
Contact Shape Square
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
