292176-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Rectangular Connector Header
PDF
/
Inventory: 9318
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Dimensions
PCB Thickness 800μm
Plating Thickness 2μm
Width 5.8mm
Length 19.7993mm
Height 7.8mm
Technical
Contact Rating (Current) 4A
Mating Post Length 4.4958mm
Insulation Diameter 930 μm
Mating Retention Without
Sealable No
Wire/Cable Gauge 22 AWG
Wire/Cable Type Discrete
Plating Tin
ELV Compliant
Operating Supply Voltage 125V
Housing Color Natural
Number of Contacts 6
Approval Agency CSA
Current Rating 4A
Orientation Vertical
Pitch 2mm
Number of Rows 1
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 6
Connector Type Header, Pin, Plug
Termination SMD/SMT
Physical
PCB Mount Alignment Without
PCB Mount Retention With
PCB Mounting Orientation Vertical
Shape Rectangular
Contact Shape Square
Mount Through Hole
Contact Plating Tin
Contact Material Brass
