281279-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings AMP-LATCH HDR LP RA 10P 15AU
PDF
/
Inventory: 9236
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Housing Material Thermoplastic
PCB Mounting Orientation Right Angle
Technical
Packaging Bulk
JESD-609 Code e3
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type Header
Color Black
Number of Rows 2
Additional Feature AMP-LATCH, LOW PROFILE, POLARIZED, SHROUDED
HTS Code 8536.69.40.40
Contact Finish - Mating GOLD (15) OVER NICKEL
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Right Angle
Depth 13.5mm
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 2
Number of Contacts 10
PCB Contact Pattern RECTANGULAR
Contact Gender Male
Operating Temperature (Min) -65°C
UL Flammability Code 94V-0
Lead Length 3.05mm
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Body/Shell Style RECEPTACLE
ELV Compliant
Polarization Key CENTER
Contact Pattern RECTANGULAR
Dimensions
Length 20.32mm
Plating Thickness 15μin
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
