281277-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 2X20P LATCH ST-LEI
PDF
/
Inventory: 7522
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Housing Material Thermoplastic
PCB Mounting Orientation Vertical
Technical
Packaging Bulk
JESD-609 Code e3
Termination Solder
ECCN Code EAR99
Connector Type Header
Color Black
Number of Rows 2
Additional Feature AMP-LATCH, LOW PROFILE, POLARIZED, SHROUDED
Contact Finish - Mating GOLD (15) OVER NICKEL
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Depth 10.2mm
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 2
Number of Contacts 40
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Contact Gender Male
Operating Temperature (Min) -65°C
UL Flammability Code 94V-0
Lead Length 3.05mm
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Insulation Resistance 1000000000Ohm
Body/Shell Style RECEPTACLE
ELV Compliant
Polarization Key CENTER
Dielectric Withstanding Voltage 1000VAC V
Contact Pattern RECTANGULAR
Dimensions
Length 58.42mm
Plating Thickness 15μin
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
