2-87655-4
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 24 MODI HDR SRRA .156CL
PDF
/
Inventory: 2859
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 50μin
Technical
Keyed Yes
Contact Rating (Current) 5A
Mating Post Length 8.76mm
Withdrawl Force-Min .278 N
Insertion Force-Max 4.448 N
Durability 75 Cycles
ELV Non-Compliant
Body/Shell Style RECEPTACLE
Insulation Resistance 5000000000Ohm
Contact Resistance 12MOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 5A
Body Depth 0.256 inch
Lead Length 6.985mm
UL Flammability Code 94V-0
Contact Gender Male
Body Breadth 0.25 inch
Contact Length - Mating 8.763mm
Number of Contacts 24
Number Of PCB Rows 1
Body Length or Diameter 3.699 inch
Approval Agency UL
Reliability COMMERCIAL
Number of Conductors ONE
Current Rating 5A
Orientation Right Angle
Pitch 3.9624mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature AMPMODU, POLARIZED
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Solder
Pbfree Code no
Packaging Bulk
Physical
PCB Mounting Orientation Right Angle
Housing Material Nylon
Mount Through Hole
Contact Plating Lead, Tin
Contact Material Brass
