2-647126-9
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Inventory: 9810
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Tin
Mount Through Hole
Contact Shape Square
Housing Material Polyester
PCB Mounting Orientation Right Angle
Technical
JESD-609 Code e3
Pbfree Code yes
Termination Solder
Connector Type Header, Pin, Plug
Color Black
Number of Rows 1
Voltage - Rated 600V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.96mm
Orientation Right Angle
Current Rating 7A
Voltage - Rated AC 600V
Number of Contacts 9
Contact Length - Mating 7.62mm
Contact Gender Male
Lead Length 3.18mm
ELV Compliant
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
