2-1586491-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Pin & Socket Connectors 22P DUAC 94V2 W0/PEG WO/DH LF
PDF
/
Inventory: 4175
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Tin
Mount Through Hole
Housing Material Nylon
PCB Mounting Orientation Vertical
Technical
JESD-609 Code e3
Termination Solder
ECCN Code EAR99
Connector Type Header, Pin, Plug
Number of Positions 22
Color Natural
Number of Rows 2
Additional Feature AMP-DUAC
HTS Code 8536.69.40.40
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 4.2mm
Total Number of Contacts 22
Current Rating 9A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 1.866 inch
Row Spacing - Mating 4.191 mm
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Body Breadth 0.394 inch
Contact Gender MALE
Operating Temperature (Min) -55°C
Body Depth 0.504 inch
Rated Current (Signal) 9A
Contact Resistance 10mOhm
Insulation Resistance 1000000000Ohm
ELV Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 1500VAC V
PCB Contact Row Spacing 5.5118 mm
Durability 30 Cycles
Contact Pattern RECTANGULAR
Dimensions
Length - Termination 0.138 inch
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Alternative Model
