RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description CONN HEADER 4POS R/A KEY-YY 30AU
PDF
/
Inventory: 3478
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

PCB Thickness 2.4mm
Length - Tail 3.8mm
Width 41.91mm
Length 29.21mm
Height 24.06mm

Technical

VDE Tested No
Preloaded Yes
Mating Alignment With
Contact Retention Without
Contact Rating (Current) 30A
Mating Retention With
Halogen Free Halogen Free
Sealable No
Max Voltage Rating (AC) 630V
ELV Compliant
Operating Supply Voltage 630V
Housing Color Black
Number of Contacts 4
Row Spacing - Mating 10.16 mm
Approval Agency UL
Current Rating 30A
Shielding Unshielded
Orientation Right Angle
Pitch 10.16mm
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Number of Positions 4
Connector Type Header, Plug, Tab
Termination Solder
Packaging Bulk

Physical

PCB Mount Retention With
PCB Mounting Orientation Right Angle
Housing Material Polyester
Mount Through Hole
Contact Plating Gold

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 5 days ago)
