194002-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Heavy Duty Power Connectors SKT ASSY.
PDF
/
Inventory: 6323
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Total Number of Contacts 6
Orientation Straight
Current Rating 19A
Approval Agency CSA
Row Spacing - Mating 6.35 mm
UL Flammability Code 94V-0
Empty Shell NO
ELV Compliant
Number of Circuits 6
Max Voltage Rating (AC) 600V
Circuit Application Power
Contact Rating (Current) 36A
VDE Tested Yes
Pitch 914.4mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature MATE-N-LOK, POLARIZED
Gender Male
Number of Rows 2
Color White
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type COMBINATION LINE CONNECTOR
Termination Solder
Pbfree Code yes
Packaging Bulk
Dimensions
Height 13.97mm
Length 20.32mm
Width 13.97mm
Plating Thickness 5.08μm
PCB Thickness 3.18mm
Compliance
Radiation Hardening No
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Physical
PCB Mounting Orientation Vertical
Housing Material Nylon
Shell Material POLYAMIDE
Mount Through Hole
Contact Plating Silver
Contact Material COPPER ALLOY
