1746315-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Automotive Connectors 0.64 2ROW 72POS CAP ASSEMBLY
PDF
/
Inventory: 4371
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width - Tab 635μm
Tab Thickness 640μm
PCB Thickness 2mm
Width 92.4052mm
Length 27.85mm
Technical
Circuit Application Signal
Max Voltage Rating (DC) 12V
ELV Compliant
Contact Length - Mating 5.5118mm
Shielding Unshielded
Orientation Right Angle
Pitch 2.2098mm
HTS Code 8536.69.40.30
Number of Rows 2
Color Natural
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Number of Positions 72
Connector Type Male Pin, Receptacle
ECCN Code EAR99
Termination Solder
Physical
Mount Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
