149011-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
HIGH DENSITY POLARZED Rectangular Connector Header
PDF
/
Inventory: 9038
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold
Mount Through Hole
Housing Material Thermoplastic
PCB Mounting Orientation Vertical
Technical
Termination Solder
ECCN Code EAR99
Connector Type Pin, Plug
Number of Positions 140
Max Operating Temperature 257°C
Min Operating Temperature -85°C
Number of Rows 2
Additional Feature HIGH DENSITY, POLARZED
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Total Number of Contacts 140
Orientation Straight
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 3.714 inch
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 5
PCB Contact Pattern STAGGERED
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender MALE
Housing Color Natural
Lead Length 3.18mm
Body Depth 0.648 inch
Contact Style SQ PIN-SKT
Insulation Resistance 5000000000Ohm
ELV Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 500VAC V
Durability 50 Cycles
Contact Pattern RECTANGULAR
Contact Rating (Current) 10.5A
Preloaded Yes
Dimensions
Height 16.51mm
Plating Thickness 30μin
Length - Tail 3.18mm
Stack Height 18.7452mm
Compliance
RoHS Status Non-RoHS Compliant
