146315-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 40 2PC VRM8 W/LATCH
PDF
/
Inventory: 4533
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
PCB Thickness 1.57mm
Contact Finish Thickness - Mating 762 nm
Plating Thickness 30μin
Technical
Mating Alignment With
Circuit Application Signal
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 750VAC V
Polarization Key POLARIZED HOUSING
Termination Type SOLDER
Body/Shell Style RECEPTACLE
Mating Contact Pitch 0.1 inch
Insulation Resistance 1GOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Operating Supply Voltage 250V
Body Depth 0.55 inch
Housing Color Black
UL Flammability Code 94V-0
Operating Temperature (Min) -65°C
Contact Gender MALE
Body Breadth 0.658 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number of Contacts 40
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Body Length or Diameter 3.1 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Reach Compliance Code compliant
Orientation Vertical
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Additional Feature LATCHED
Number of Rows 2
Color White
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Pbfree Code no
Packaging Bulk
Physical
PCB Mount Alignment Without
Mounting Option 2 LOCKING
Mounting Style STRAIGHT
Mounting Option 1 LATCH & EJECT
Housing Material Thermoplastic
Mounting Type BOARD
Contact Plating Gold
Contact Material NOT SPECIFIED
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
