1375582-4 image
Favorite
1375582-4 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Rectangular Connector Header
PDF
/
Inventory: 8237
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

PCB Thickness 1.57mm
Contact Finish Thickness - Mating 381 nm

Technical

Contact Rating (Current) 3A
Mating Retention Without
Wire/Cable Type Discrete
Plating Gold
ELV Non-Compliant
Insulation Resistance 5GOhm
Operating Supply Voltage 250V
Housing Color Black
Contact Gender Male
Number of Contacts 5
Row Spacing - Mating 2.54 mm
Approval Agency CSA
Current Rating 3A
Orientation Vertical
Pitch 2.54mm
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Number of Positions 5
Connector Type Header, Pin, Plug
Termination Crimp
Packaging Tape & Reel

Physical

PCB Mount Retention With
PCB Mounting Orientation Vertical
Housing Material Thermoplastic
Mount Surface Mount
Contact Plating Gold, Tin
Contact Material Brass

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
