102322-8 image
Favorite
102322-8 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Headers & Wire Housings 034 UNIV HDR RA 4S 3
PDF
/
Inventory: 3156
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Length - Termination 0.155 inch

Technical

Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 1000VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Body/Shell Style PLUG
Insulation Resistance 1000000000Ohm
Contact Style SQ PIN-SKT
Rated Current (Signal) 1A
Body Depth 0.549 inch
Lead Length 3.94mm
UL Flammability Code 94V-0
Operating Temperature (Min) -65°C
Contact Gender Male
Body Breadth 0.336 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 6.096mm
Number of Contacts 34
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Orientation Right Angle
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Latch
HTS Code 8536.69.40.40
Additional Feature POLARIZED
Number of Rows 2
Color Black
Connector Type Header
ECCN Code EAR99
Termination Solder
Pbfree Code no
JESD-609 Code e0
Packaging Bulk

Physical

PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Contact Shape Square
Mount Through Hole
Contact Plating Gold
Contact Material Bronze

Alternative Model
