1-794630-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 3MM 12POS DUAL TIN
PDF
/
Inventory: 8498
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Contact Plating Lead, Tin
Mount Through Hole
Shell Material POLYAMIDE
Housing Material Nylon
Technical
Packaging Bulk
JESD-609 Code e3
Number of Terminations 12
Termination Through Hole
ECCN Code EAR99
Connector Type Header, Pin, Plug
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Black
Number of Rows 2
Gender Male
Voltage - Rated 250V
HTS Code 8536.69.40.30
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3mm
Total Number of Contacts 12
Orientation Straight
Depth 6.86mm
Current Rating 5A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Row Spacing - Mating 3 mm
Number Of PCB Rows 2
Lead Pitch 3mm
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-0
Lead Length 3.18mm
Empty Shell NO
Rated Current (Signal) 5A
Contact Style SQ PIN-SKT
ELV Non-Compliant
Max Voltage Rating (AC) 250V
Polarization Key POLARIZED HOUSING
Number of Ports 1
Contact Pattern RECTANGULAR
Withdrawl Force-Min .695 N
Dimensions
Length 22mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
