1-794588-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Pin & Socket Connectors 18P DUAC RA HDR ASSY W/PEGS LF
PDF
/
Buying Options
Total Price: USD $4.65
Unit Price: USD $4.646102
≥1 USD $4.646102
≥10 USD $4.383123
≥100 USD $4.135014
≥500 USD $3.900965
≥1000 USD $3.680159
Inventory: 1473
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Tin
Mount Through Hole
Shell Material POLYAMIDE
Housing Material Nylon
PCB Mounting Orientation Right Angle
Technical
Packaging Bulk
JESD-609 Code e3
Number of Terminations 18
Termination Solder
Connector Type Header, Pin, Plug
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color White
Number of Rows 2
Additional Feature AMP-DUAC
Fastening Type Ramp
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 4.2mm
Total Number of Contacts 18
Orientation Right Angle
Depth 12.8mm
Current Rating 9A
Row Spacing - Mating 4.191 mm
Contact Gender MALE
UL Flammability Code 94V-0
Empty Shell NO
ELV Compliant
Max Voltage Rating (AC) 600V
Number of Ports 1
Dimensions
Length 39mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
