1-794515-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
AMP-DUAC Rectangular Connector Header
PDF
/
Inventory: 4443
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 150μin
Length 9.6mm
Technical
Mating Contact Row Spacing 0.165 inch
Withdrawl Force-Min .1946 N
Contact Pattern RECTANGULAR
PCB Contact Row Spacing 5.5118 mm
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 600V
ELV Compliant
Insulation Resistance 1000000Ohm
Contact Resistance 10mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 9A
Empty Shell NO
Housing Color Natural
Body Breadth 0.449 inch
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 9A
Depth 12.8mm
Orientation Right Angle
Total Number of Contacts 22
Pitch 4.2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.30
Additional Feature AMP-DUAC
Gender Male
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 22
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Solder
Pbfree Code yes
JESD-609 Code e3
Physical
PCB Mounting Orientation Right Angle
Mounting Option 1 LOCKING
Housing Material Nylon
Shell Material POLYAMIDE
Mounting Type BOARD
Contact Plating Tin
