1-794486-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 08P AMP/DUAC VRT HDR ASSY LF
PDF
/
Buying Options
Total Price: USD $4.85
Unit Price: USD $4.853482
≥1 USD $4.853482
≥10 USD $4.57876
≥100 USD $4.319578
≥500 USD $4.075076
≥1000 USD $3.844412
Inventory: 984
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Contact Pattern RECTANGULAR
Durability 30 Cycles
Dielectric Withstanding Voltage 1500VAC V
Polarization Key POLARIZED HOUSING
Insulation Resistance 1000000000Ohm
Contact Resistance 10mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 9A
Body Depth 0.504 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Contact Gender MALE
Body Breadth 0.394 inch
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Row Spacing - Mating 4.191 mm
Body Length or Diameter 0.709 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 9A
Total Number of Contacts 8
Pitch 4.2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
Additional Feature AMP-DUAC
Number of Rows 2
Color White
Number of Positions 8
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Solder
Packaging Bulk
Physical
PCB Mounting Orientation Vertical
Housing Material Nylon
Mount Through Hole
Contact Plating Tin
