1-794307-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Pin & Socket Connectors AMPDUAC PWR CONN 12P VRT ASSY LF
PDF
/
Inventory: 3152
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length - Termination 0.138 inch
Plating Thickness 30μin
Technical
Insertion Force-Max .5004 N
Contact Pattern RECTANGULAR
Durability 30 Cycles
PCB Contact Row Spacing 5.5118 mm
Dielectric Withstanding Voltage 1500VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Insulation Resistance 1000000000Ohm
Contact Resistance 10mOhm
Rated Current (Signal) 9A
Body Depth 0.504 inch
Operating Temperature (Min) -55°C
Contact Gender MALE
Body Breadth 0.394 inch
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Row Spacing - Mating 4.191 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 9A
Total Number of Contacts 12
Pitch 4.2mm
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
Number of Rows 2
Color Natural
Number of Positions 12
Connector Type Header, Pin, Plug
Termination Solder
Packaging Bulk
Physical
PCB Mounting Orientation Vertical
Housing Material Nylon
Mount Through Hole
Contact Plating Gold
