1-641210-4
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings FRCTN LK HDR RA 14P Square post gold
PDF
/
Inventory: 4572
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold
Mount Through Hole
Contact Shape Square
Housing Material Polyester
PCB Mounting Orientation Right Angle
Underplate Material Nickel
Technical
Termination Solder
Connector Type Header, Pin, Plug
Number of Positions 14
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Natural
Number of Rows 1
Voltage - Rated 600V
Fastening Type Friction
Pitch 3.9624mm
Orientation Right Angle
Current Rating 7A
Voltage - Rated AC 600V
Approval Agency CSA
Shrouding No
Number of Contacts 14
Contact Length - Mating 10.16mm
Contact Gender Male
Housing Color Natural, White
Lead Length 3.18mm
Operating Supply Voltage 600V
ELV Compliant
Mating Post Length 10.16mm
Contact Rating (Current) 7A
Dimensions
Height 10.795mm
Length 55.47mm
Plating Thickness 1.27μm
Length - Tail 3.18mm
PCB Thickness 1.6002mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
