1-641121-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 15P MTA156 HDR ASSY FL/RA 15AU
PDF
/
Inventory: 4242
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Gold
Mount Through Hole
Contact Shape Square
Housing Material Polyester
PCB Mounting Orientation Right Angle
Technical
JESD-609 Code e0
Pbfree Code no
Termination Through Hole
ECCN Code EAR99
Connector Type Header, Pin, Plug
Number of Rows 1
Voltage - Rated 600V
Additional Feature AMP
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.96mm
Orientation Right Angle
Current Rating 7A
Number of Conductors ONE
Reference Standard UL, CSA
Voltage - Rated AC 600V
Reliability COMMERCIAL
Body Length or Diameter 2.34 inch
Shrouding No
Number Of PCB Rows 1
Number of Contacts 15
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.3 inch
Contact Gender Male
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Housing Color White
Lead Length 3.18mm
Body Depth 0.659 inch
Rated Current (Signal) 7A
Contact Style SQ PIN-SKT
Contact Resistance 3mOhm
Insulation Resistance 5000000000Ohm
ELV Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 2200VAC V
Durability 25 Cycles
Contact Pattern RECTANGULAR
Insulator Color NATURAL
Mating Post Length 10.16mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
