1-215243-6 image
Favorite
1-215243-6 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Headers & Wire Housings AMP-LATCH UNIV.HDR.
PDF
/
Inventory: 2641
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Bronze
Contact Plating Tin
Mount Through Hole
Housing Material Thermoplastic
PCB Mounting Orientation Vertical

Technical

Packaging Bulk
JESD-609 Code e3
Pbfree Code yes
Termination Press-Fit
ECCN Code EAR99
Connector Type Header
Color Black
Number of Rows 2
Additional Feature AMP-LATCH
HTS Code 8536.69.40.40
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Depth 8.5mm
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 2
Number of Contacts 16
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Body Breadth 0.335 inch
Contact Gender Male
Operating Temperature (Min) -65°C
Lead Length 4mm
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Contact Resistance 8mOhm
Insulation Resistance 1000000000Ohm
Body/Shell Style RECEPTACLE
Polarization Key CTR W/GUIDE SLOTS
Dielectric Withstanding Voltage 1000VAC V
Contact Pattern RECTANGULAR

Dimensions

Length 39.6mm
Plating Thickness 31μin

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
