1-1318382-0
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Inventory: 8548
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 HB
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width - Tab 635μm
Tab Thickness 640μm
PCB Thickness 1.6mm
Width 23.0124mm
Length 24.4602mm
Technical
Number of Signal Positions 16
Circuit Application Signal
Max Voltage Rating (DC) 12V
ELV Compliant
Housing Color Black
Contact Length - Mating 5.5118mm
Number of Contacts 16
Shielding Unshielded
Orientation Right Angle
Pitch 2.2098mm
Number of Rows 2
Color Black
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Number of Positions 16
Connector Type Male Pin, Receptacle
Termination Solder
Physical
Mount Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
