446852-9

TE Connectivity
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Rectangular Connector Header
PDF
/
Inventory: 8087
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Plating Thickness 50μin
Length 133.35mm

Technical

Mating Contact Row Spacing 0.1 inch
Contact Pattern RECTANGULAR
Polarization Key ENDS
ELV Compliant
Body/Shell Style RECEPTACLE
Contact Style SQ PIN-SKT
Body Depth 0.75 inch
Lead Length 3.56mm
Contact Gender MALE
Body Breadth 0.495 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 3
Number of Conductors ONE
Orientation Right Angle
Total Number of Contacts 135
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Subcategory Headers and Edge Type Connectors
Number of Rows 3
Color Brown
Number of Positions 135
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Solder
Pbfree Code no
JESD-609 Code e0
Packaging Bulk

Physical

Housing Material Polyphenylene
Mount Through Hole
Contact Plating Gold
Contact Material Brass
