207441-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER PIN 9POS VERT TIN
PDF
/
Inventory: 9931
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
PCB Thickness 1.6002mm
Length - Tail 4.5974mm
Plating Thickness 3.81μm
Width 24.23mm
Length 27.69mm
Height 11.79mm
Technical
VDE Tested Yes
Contact Rating (Current) 7.5A
Durability 2000 Cycles
Number of Ports 1
Dielectric Withstanding Voltage 600VAC V
Max Voltage Rating (AC) 600V
ELV Non-Compliant
Body/Shell Style PLUG
Insulation Resistance 5000000000Ohm
Contact Style RND PIN-SKT
Empty Shell NO
Contact Gender Male
Body Breadth 0.7 inch
Lead Pitch 5mm
Number Of PCB Rows 3
Row Spacing - Mating 5.0038 mm
Approval Agency UL
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 14A
Depth 27.69mm
Total Number of Contacts 9
Pitch 5.0038mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Latch
Additional Feature PIN HEADER
Voltage - Rated 600V
Number of Rows 3
Color Red
Min Operating Temperature -55°C
Max Operating Temperature 130°C
Connector Type Header, Pin, Receptacle
Termination Solder
Number of Terminations 9
Part Status Active
Pbfree Code no
Published 2005
Packaging Bulk
Physical
PCB Mounting Orientation Vertical
Housing Material Nylon
Shell Material POLYETHYLENE
Mount Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 17 Weeks
