175521-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Automotive Connectors HYBRID I/O CAP ASY 38P GRAY
PDF
/
Buying Options
Total Price: USD $27.54
Unit Price: USD $27.5386
≥1 USD $27.5386
≥10 USD $22.59575
≥100 USD $21.8899
≥500 USD $21.18405
≥1000 USD $20.4782
Inventory: 3363
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 HB
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width - Tab 1.8034mm
Tab Thickness 640μm
PCB Thickness 1.6mm
Width 73.9mm
Length 25.8064mm
Technical
Circuit Application Signal
Max Voltage Rating (DC) 12V
ELV Compliant
Empty Shell NO
Contact Length - Mating 7.112mm
Row Spacing - Mating 5.207 mm
Depth 25.8mm
Shielding Unshielded
Orientation Right Angle
Total Number of Contacts 38
Pitch 2.9972mm
Option GENERAL PURPOSE
Mixed Contacts YES
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature MULTILOCK
Gender Female
Number of Rows 2
Color Grey
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Number of Positions 38
Connector Type Receptacle, Tab
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 1997
Packaging Bulk
Physical
Housing Material Polybutylene
Mount Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 6 Weeks
