173856-1

TE Connectivity
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Automotive Connectors 070 MULTI LK ASSY 8P WHITE
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
Inventory: 3631
Minimum: 1
-
+

Technical Details

Compliance

Flammability Rating UL94 HB
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width - Tab 1.8034mm
Tab Thickness 640μm
PCB Thickness 1.6mm
Width 39.3mm
Length 24.92mm

Technical

Circuit Application Signal
Max Voltage Rating (DC) 12V
ELV Compliant
Empty Shell NO
Row Spacing - Mating 5.8928 mm
Depth 18.6mm
Shielding Unshielded
Orientation Right Angle
Total Number of Contacts 8
Pitch 3.5mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating GOLD
Additional Feature MULTI-LOCK
Gender Female
Number of Rows 2
Color White
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Number of Positions 8
Connector Type Receptacle, Tab
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e0
Published 2005
Packaging Bulk

Physical

Housing Material Polybutylene
Mount Through Hole
Contact Plating Tin
Contact Material Brass

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 17 Weeks
