172258-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Rectangular Connector Header
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.6916
≥1 USD $0.6916
≥10 USD $0.5681
≥100 USD $0.55005
≥500 USD $0.532
≥1000 USD $0.5149
Inventory: 3655
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 HB
RoHS Status RoHS Compliant
Dimensions
Width - Tab 635μm
Tab Thickness 640μm
Width 27.5082mm
Length 18.1mm
Technical
Number of Signal Positions 16
Circuit Application Signal
Max Voltage Rating (DC) 12V
ELV Compliant
Housing Color Black
Contact Length - Mating 8.509mm
Number of Contacts 16
Row Spacing - Mating 4.5974 mm
Depth 18.1mm
Shielding Unshielded
Orientation Vertical
Pitch 2.9972mm
Fastening Type Ramp
Number of Rows 2
Color Black
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Number of Positions 16
Connector Type Male Pin, Receptacle
Termination Solder
Physical
Housing Material Nylon
Mount Through Hole
Contact Plating Tin
Contact Material Bronze
