1717394-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Automotive Connectors 0.64 SMD 24POS CAP ASSY V TIN
PDF
/
Buying Options
Total Price: USD $2.58
Unit Price: USD $2.5784
≥1 USD $2.5784
≥10 USD $2.297478
≥100 USD $2.039488
≥500 USD $1.875368
≥1000 USD $1.676118
≥3000 USD $1.453408
Inventory: 489
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width - Tab 635μm
Tab Thickness 640μm
Width 41.4mm
Length 16.2mm
Technical
Number of Signal Positions 24
Circuit Application Signal
Max Voltage Rating (DC) 12V
ELV Compliant
Housing Color Black
Contact Length - Mating 5.6896mm
Number of Contacts 24
Row Spacing - Mating 2.9972 mm
Depth 16.2mm
Shielding Unshielded
Orientation Vertical
Pitch 2.2098mm
Number of Rows 2
Color Black
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Number of Positions 24
Connector Type Male Pin, Receptacle
Termination SMD/SMT
Part Status Active
Published 2005
Physical
Housing Material Polyphenylene
Mount Surface Mount
Contact Plating Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 18 Weeks
