146128-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 04 MODII HDR SR SFMNT B/A .100
PDF
/
Inventory: 4885
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
PCB Thickness 1.5748mm
Plating Thickness 30μin
Length 9.75mm
Technical
High Temperature Compatible Yes
High Speed Serial Data Connector No
Contact Rating (Current) 3A
Mating Post Length 5.842mm
Insertion Force-Max 2.502 N
Contact Pattern RECTANGULAR
Durability 200 Cycles
PCB Contact Row Spacing 2.667 mm
Dielectric Withstanding Voltage 750VAC V
ELV Non-Compliant
Body/Shell Style RECEPTACLE
Insulation Resistance 5GOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 2A
Operating Supply Voltage 30V
Lead Length 2.29mm
Contact Gender Male
Body Breadth 0.092 inch
PCB Contact Pattern STAGGERED
Contact Length - Mating 5.842mm
Number of Contacts 4
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Approval Agency CSA
Reliability COMMERCIAL
Number of Conductors ONE
Current Rating 3A
Depth 2.34mm
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Additional Feature AMPMODU
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Connector Type Header, Pin, Plug
Termination SMD/SMT
Part Status Active
Pbfree Code no
JESD-609 Code e0
Published 2011
Physical
PCB Mounting Orientation Vertical
Housing Material Polymer
Contact Shape Square
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 months ago)
Factory Lead Time 12 Weeks
