1-530761-3
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Inventory: 3351
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Plating Thickness 50μin
Technical
Mating Contact Row Spacing 0.1 inch
Contact Pattern RECTANGULAR
Polarization Key POLARIZED KEY
Termination Type SURFACE MOUNT
Body/Shell Style RECEPTACLE
Contact Style SQ PIN-SKT
Body Depth 0.5 inch
Lead Length 3.18mm
Contact Gender MALE
Body Breadth 0.31 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Number of Conductors ONE
Orientation Right Angle
Total Number of Contacts 120
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Color Blue
Connector Type Header, Pin, Plug
Packaging Bulk
Physical
Number of Pins 120
Mount Straddle Mount
Contact Plating Gold
Contact Material Brass
