1-2229803-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
TE CONNECTIVITY 1-2229803-2Wire-To-Board Connector, Dynamic D-3950 Series, Through Hole, Header, 7 Contacts, 7.5 mm
PDF
/
Inventory: 3899
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Length - Tail 3.8mm
Width 18.1mm
Length 81.788mm
Height 11.9888mm
Technical
VDE Tested No
Preloaded Yes
Contact Rating (Current) 14.5A
Halogen Free Halogen Free
ELV Compliant
Operating Supply Voltage 600V
Housing Color Black
Number of Contacts 7
Shielding Unshielded
Orientation Right Angle, Horizontal
Pitch 7.493mm
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Number of Positions 7
Connector Type Header, Plug, Tab
Termination Solder
Part Status Active
Published 2013
Physical
PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Mount Through Hole
Contact Plating Gold, Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Alternative Model
