S9692E-01
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.088
≥1 USD $0.088
≥10 USD $0.0088
≥100 USD $0.002376
≥500 USD $0.002006
Inventory: 574
Minimum: 1
-
+
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -65°C~125°C
Packaging Bulk
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header, Breakaway
Number of Positions 1
Fastening Type Push-Pull
Contact Finish - Mating Tin
Contact Type Male Pin
Current Rating (Amps) 3A
Insulation Height 0.100 2.54mm
Style Board to Board or Cable
Number of Positions Loaded All
Insulation Color Black
Contact Length - Post 0.120 3.05mm
Shrouding Unshrouded
Contact Length - Mating 0.318 8.08mm
Overall Contact Length 0.538 13.67mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
