TSW-103-07-T-D-006
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
POLARIZED Male Pin Rectangular Connector
PDF
/
Inventory: 8068
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Technical
Overall Contact Length 0.430 10.92mm
UL Flammability Code 94V-0
Contact Length - Mating 0.230 5.84mm
Lead Pitch 2.54mm
Shrouding Unshrouded
Contact Length - Post 0.100 2.54mm
Row Spacing - Mating 0.100 (2.54mm)
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded 5
Style Board to Board or Cable
Insulation Height 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Tin
Fastening Type Push-Pull
Additional Feature POLARIZED
Gender Male
Number of Rows 2
Number of Positions 6
Connector Type Header
ECCN Code EAR99
Termination Solder
Part Status Active
JESD-609 Code e3
Series TSW
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Insulation Material Polybutylene Terephthalate (PBT)
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
