TSW-101-13-T-S-RE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
.025 Sq. Terminal Strips
PDF
/
Inventory: 4669
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polybutylene Terephthalate (PBT)
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Series TSW
JESD-609 Code e3
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type Header
Number of Positions 1
Number of Rows 1
HTS Code 8536.69.40.40
Fastening Type Push-Pull
Contact Finish - Mating Tin
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Insulation Height 0.100 2.54mm
Style Board to Board or Cable
Number of Positions Loaded All
Insulation Color Black
Contact Length - Post 0.900 22.86mm
Shrouding Unshrouded
Lead Pitch 2.54mm
Contact Length - Mating 0.230 5.84mm
UL Flammability Code 94V-0
Overall Contact Length 1.230 31.24mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
