TSS-118-02-T-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Flex Stack TSS ROHS3Compliant GENERAL PURPOSE Keying Slot Connector Header -55C~105C 0.250 6.35mm
PDF
/
Inventory: 6343
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Technical
Overall Contact Length 0.530 13.46mm
Contact Length - Mating 0.250 6.35mm
Shrouding Shrouded - 4 Wall
Contact Length - Post 0.165 4.19mm
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.350 8.89mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Tin
Fastening Type Push-Pull
Gender Male
Number of Rows 1
Number of Positions 18
Connector Type Header
Termination Solder
Part Status Active
Pbfree Code yes
Feature Keying Slot
JESD-609 Code e3
Series Flex Stack, TSS
Packaging Tube
Operating Temperature -55°C~105°C
Physical
Insulation Material Polybutylene Terephthalate (PBT)
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
