TMMH-134-04-T-D
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
SAMTEC TMMH-134-04-T-D Board-To-Board Connector, Vertical, TMMH Series, 68 Contacts, Header, 2 mm, Through Hole, 2 Rows
PDF
/
Inventory: 8371
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Bronze
Contact Plating Tin
Mount Through Hole
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Technical
Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type BOARD CONNECTOR
Number of Rows 2
Gender Male
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2mm
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 2
Number of Contacts 68
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Body Breadth 0.157 inch
Operating Temperature (Min) -65°C
Body Depth 0.079 inch
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Insulation Resistance 5000000000Ohm
Body/Shell Style RECEPTACLE
Dielectric Withstanding Voltage 1000VAC V
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.079 inch
Insulator Color BLACK
Dimensions
Plating Thickness 150μin
Length - Termination 0.101 inch
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
