TLW-123-01-T-S-LA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
LOW PROFILE Male Pin Rectangular Connector
PDF
/
Inventory: 1449
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material PHOSPHOR BRONZE
Contact Plating Tin
Mount Through Hole
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Technical
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type BOARD CONNECTOR
Number of Rows 1
Gender Male
Additional Feature LOW PROFILE
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Number of Conductors ONE
Reliability COMMERCIAL
Body Length or Diameter 2.3 inch
Number Of PCB Rows 1
Number of Contacts 23
PCB Contact Pattern RECTANGULAR
Body Breadth 0.098 inch
Operating Temperature (Min) -55°C
Body Depth 0.06 inch
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Body/Shell Style RECEPTACLE
Contact Pattern RECTANGULAR
Insulator Color BLACK
Compliance
RoHS Status ROHS3 Compliant
