TFM-145-02-SM-D-K
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Buying Options
Total Price: USD $58.7
Unit Price: USD $58.703698
≥1 USD $58.703698
≥198 USD $23.423449
≥504 USD $22.640961
≥999 USD $22.253655
Inventory: 3600
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series Tiger Eye? TFM
JESD-609 Code e3
Feature Pick and Place
Part Status Active
Termination Solder
Connector Type Header
Number of Positions 90
Number of Rows 2
Gender Male
Voltage - Rated 275VAC
Fastening Type Push-Pull
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 2.9A per Contact
Total Number of Contacts 90
Insulation Height 0.220 5.60mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.050 1.27mm
Insulation Color Black
Number of Conductors ONE
Reliability COMMERCIAL
Row Spacing - Mating 0.050 (1.27mm)
Shrouding Shrouded - 4 Wall
Number Of PCB Rows 2
Contact Finish - Post Tin
Contact Length - Mating 0.131 3.33mm
PCB Contact Pattern RECTANGULAR
UL Flammability Code 94V-0
Mating Contact Pitch 0.05 inch
Dimensions
Plating Thickness 30μin
Contact Finish Thickness - Mating 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
