TFC-125-02-L-D-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
SAMTEC TFC-125-02-L-D-A Wire-To-Board Connector, TFC Series, Surface Mount, Header, 50 Contacts, 1.27 mm
PDF
/
Buying Options
Total Price: USD $6.73
Unit Price: USD $6.732
≥1 USD $6.732
≥10 USD $6.2216
≥100 USD $5.8784
≥500 USD $5.6672
≥1000 USD $4.3208
≥3000 USD $3.872
Inventory: 58
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Plating Thickness 10μin
Technical
Polarization Key POLARIZED HOUSING
Mating Contact Pitch 0.05 inch
Contact Resistance 15mOhm
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 0.133 3.38mm
Contact Finish - Post Tin
Number Of PCB Rows 2
Shrouding Shrouded - 4 Wall
Row Spacing - Mating 0.050 (1.27mm)
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.050 1.27mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.225 5.72mm
Total Number of Contacts 50
Current Rating (Amps) 3.1A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Additional Feature TIGER EYE SYSTEM, SHROUDED
Voltage - Rated 275VAC
Gender Male
Number of Rows 2
Number of Positions 50
Connector Type Header
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
JESD-609 Code e3
Series Tiger Eye? TFC
Published 2013
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
Alternative Model
