MTSW-130-07-T-Q-250
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Unshrouded Header HDR 60 POS 2.54mm Solder ST Thru-Hole
PDF
/
Inventory: 6143
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polyester, Glass Filled
Housing Material Polyester
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2016
Series Flex Stack, MTSW
JESD-609 Code e3
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type Header, Cuttable
Number of Positions 60
Number of Rows 2
Gender Male
HTS Code 8536.69.40.40
Fastening Type Push-Pull
Contact Finish - Mating Tin
Contact Type Male Pin
Orientation Straight
Depth 7.62mm
Insulation Height 0.100 2.54mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Row Spacing - Mating 0.200 (5.08mm)
Contact Length - Post 0.080 2.03mm
Shrouding Unshrouded
Lead Pitch 2.54mm
Contact Length - Mating 0.250 6.35mm
Overall Contact Length 0.430 10.92mm
Max Current Rating 3A
Dimensions
Length 76.2mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Lead Free Lead Free
