MTSW-104-07-T-D-175
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Unshrouded Header HDR 8 POS 2.54mm Solder ST Thru-Hole
PDF
/
Inventory: 6129
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polyester, Glass Filled
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2016
Series Flex Stack, MTSW
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Solder
Connector Type Header, Cuttable
Number of Positions 8
Number of Rows 2
Gender Male
Fastening Type Push-Pull
Contact Finish - Mating Tin
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 3A
Insulation Height 0.100 2.54mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Row Spacing - Mating 0.100 (2.54mm)
Contact Length - Post 0.155 3.94mm
Shrouding Unshrouded
Lead Pitch 2.54mm
Contact Length - Mating 0.175 4.45mm
Overall Contact Length 0.430 10.92mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
